HK60-Q-G High Pressure Stainless Steel Electric Actuated Ball Valve
SS High Pressure Electric Actuator Operated Ball Valve
COVNA 2-way ultra-high pressure ball valve uses a 90-degree rotation of the ball core to achieve opening and closing. It is manufactured through a high-pressure forging process and is equipped with sealing components imported from Germany to ensure the initial sealing effect. The stainless steel butterfly spring washer further strengthens the packing sealing surface, enabling it to provide excellent self-sealing performance when the medium pressure rises. This ultra-high pressure ball valve is not only suitable for ultra-high pressure liquids, but also can handle ultra-high pressure gases and their mixed media. It is widely used in industries such as ultra-high pressure testing machines, pneumatic pumps, hydraulic pumps and deep-sea detection equipment.
Technical Parameters of Valve Actuator
| ON/OFF Type | Feedback: the active contact signal, passive contact signal, resistance, 4-20mA |
| Regulation Type | Input & Output signal: DC 4-20mA, DC 0-10V, DC 1-5V |
| Field operation | The Field, Remote Control Switch Regulation and MODBUS, PROFIBUS Field Bus |
| Voltage Optional | AC110-240V 380V 50/60HZ: DC12V, DC24V, Special Voltage Can be Customized |
| Protection Class | IP65, Explosion Proof Construction Are Available: EX ll BT4 |
Technical Parameters of Valve Body
| Valve Body | Valve components | ||
| Nominal size | DN15-DN200 | Sealing material | PTFE: -20℃~180℃
PPL: -29℃~250℃ |
| Body Material | Stainless Steel | Disc Material | SS304, SS316, SS316L |
| End Connection | Thread | Stem Material | Stainless Steel |
| Operating Pressure | 1.6 ~ 40 MPa ( 16 ~ 40 bar) | Applicable media | Water, Air, Gas, Steam, Oil, Liquid |
| Structure | Floating ball core | Design standard | ISO, DIN, IDF, SMS, 3A |
