HK17C-C Y Type Pneumatic Angle Seat Valve – Tri Clamp Connection

Short Description:

HK17C-C Y Type Pneumatic Angle Seat Valve

with tri-clamp connection type. Compact structure and small flow resistance. Widely used in food & beverage industry. Offering various Y-type pneumatic angle seat valves in all sizes and all function type for your choice. Consult us to get a suitable valve for your project!

Model

Actuator Material: Stainless Steel
Body Material: Stainless Steel
Medium Temperature: -20 to 180℃
Working Pressure: 16 Bar
Connection Type: Clamp
Control Type: Spring Return / Double Acting

Get A Quick Quote Download Datasheet

Product Detail

Product Tags

Technical Parameters Of Tri-clamp Pneumatic Angle Seat Valve

Actuator Material	Stainless Steel	Ambient Temperature	-30°C to 80°C
Body Material	Stainless Steel	Suitable Medium	Water, Oil, Air, Gas, etc
Stem Material	304, 316, 316L	Medium Temperature	-20°C to 180℃
Seat Material	PTFE, F46	Working Pressure	16 Bar
Connection Type	Clamp	Controlling pressure	0.3 to 0.8BMPa
Optional accessory	Solenoid valve, limit switch box, positioner, etc	Control Type	Spring Return / Double Acting
